Capsule Processing Equipment

The AMTCCL Automatic Capsule Loader is designed to work in conjunction with manually operated capsule filling machines. The system automatically loads capsules into the loading tray in the correct cap-up, body-down orientation, eliminating the need for manual capsule loading and significantly improving productivity and operator convenience.

Applications.

Ideal for use with manual capsule filling machines in pharmaceutical, herbal, nutraceutical, and research laboratories where accurate and efficient capsule loading is required.

Features

• Automatic capsule loading and orientation.

• Reduces manual handling and operator fatigue.

• Improves loading speed and consistency.

• Suitable for pharmaceutical and nutraceutical production applications.

• Robust and easy-to-operate design.

Capsule Size Compatibility

• Sizes 00, 0, 1, and 2: Compatible with the same machine through change parts.

• Sizes 3 and 4: Require a separate machine configuration.

• Size 5: Requires an independent machine setup.

Electrical Specifications

• 415 V AC, 3 Phase, 50 HzOR220 V AC, 1 Phase, 50 Hz

The De-Blistering Machine is a semi-automatic unit designed for safe and efficient recovery of tablets and capsules from rejected blister packs. Built in compliance with GMP standards, it features SS 316 contact parts for hygienic, contamination-free operation. Equipped with a synchronized motor and rubber pinch roller mechanism, the machine gently separates products from blisters, minimizing damage while maximizing recovery. Its adjustable design accommodates various blister pack sizes and ensures consistent performance in pharmaceutical production and quality control environments.

Key Highlights:

• Compatible with PVC–Alu, PVDC–Alu & Alu–Alu blisters.

• Output up to 40–50 blisters per minute.

• SS 316 contact parts for hygienic operation.

• Adjustable settings for different blister pack sizes.

• Gentle operation to minimize tablet/capsule damage.

• Compact design with castor wheel mobility.

• Integrated safety guards for safe operation.

The Strip De-Foiling Machine is designed for efficient recovery of tablets and capsules from strip packs, ensuring high productivity with its multi-track operation. Built with SS 316 contact parts for hygienic, GMP-compliant performance, it features a precision roller and slitter mechanism for smooth and effective de-foiling. The machine is equipped with a VFD-controlled drive, adjustable speed, and forward-reverse functionality, offering flexibility for different strip formats while maintaining consistent recovery with minimal product damage.

Key Highlights:

• Dual-track system for higher efficiency.

• SS 316 contact parts for hygienic operation.

• VFD-based speed control with forward/reverse function.

• Adjustable settings for different strip sizes.

• Smooth de-foiling with minimal product damage.

• Recovery ratio up to 95% (tablets) and 80–95% (capsules)
