Dust Collection & Air Handling Systems

Centrifugal Fans and Vacuum Blowers are designed and manufactured for efficient air handling, suction, ventilation, dust extraction, and pneumatic conveying applications in pharmaceutical, chemical, food, and process industries. The systems are engineered specifically as per customer process requirements, airflow capacity, static pressure, and system design parameters to ensure optimum performance and energy efficiency.

These units are widely used in applications such as Dust Collectors (DC), Fluid Bed Dryer (FBD), Auto Coater, Vacuum Material Conveying Systems, Process Exhaust Systems, AHU Applications, and other industrial air handling operations. The blowers are available in SS or MS Painted construction depending on process conditions, environmental requirements, and application suitability.

The impeller is dynamically balanced for vibration-free operation, low noise level, and long service life. Different impeller and blade configurations such as Backward Curved, Forward Curved, and Radial Blade designs are provided based on airflow characteristics, pressure requirement, material handling properties, and overall system efficiency.

The blower assembly can be supplied with inlet or outlet dampers for precise air flow control and system balancing. Maintenance window and drain point provisions are incorporated for easy inspection, cleaning, and maintenance access during operation. The robust construction ensures reliable continuous-duty performance with minimum maintenance requirement.

Motor specifications can be provided as per customer requirement including IE2, IE3 energy-efficient motors, Flameproof (FLP) or Non-FLP execution, and suitable IP protection ratings for different operating environments and hazardous area classifications. Capacity, pressure range, motor rating, drive arrangement, and mounting configuration can be customized as per process application and customer specifications.

A Dust Collector is an essential air handling and pollution control system designed to efficiently capture, filter, and remove dust particles generated during various industrial manufacturing and material handling processes. Our Dust Collection System is engineered for reliable performance, low maintenance, and continuous operation in pharmaceutical, chemical, food, powder processing, and general industrial applications.

The unit is manufactured in high-quality SS or MS Painted construction as per process and environmental requirements, ensuring robust structure, corrosion resistance, and long service life. The system is available with Filter Bag or Filter Cartridge type filtration arrangement, selected based on application, dust characteristics, and required filtration efficiency.

The Dust Collector is equipped with an automatic air purging cleaning system incorporating Pulse Jet Valves, Air Header, Solenoid Valves, and Timer Card Controller for periodic cleaning of filter media during operation. This automatic pulse cleaning mechanism maintains optimum airflow, reduces pressure drop, and enhances filter life while ensuring consistent dust collection efficiency.

The system is designed with suitable blower capacity, filtration area, and hopper arrangement as per process requirement and system design calculations. Compact construction, easy maintenance access, efficient dust separation, and low operational noise make the system suitable for both standalone and centralized dust extraction applications.

Capacity, airflow, filtration area, and overall system configuration can be customized as per customer process requirements and application conditions.
